Grup Tangki Udara Depan Truk Traktor Seri Dongfeng DFL4251A8-T31R-931-02

The Dongfeng DFL4251A8-T31R-931-02 series tractor truck is renowned for its robust air brake system, which ensures reliable performance and safety under various driving conditions. At the heart of this system is the front air reservoir group, a critical component designed to store and manage compressed air. This detailed description will cover the various elements that make up the air reservoir group, including their functions and interconnections.

Product Parameters of Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck Front Air Reservoir Group

Grup Tangki Udara Depan Truk Traktor Seri Dongfeng DFL4251A8-T31R-931-02
Majelis Reservoir Udara
Itu air reservoir assembly is a central component of the front air reservoir group. This cylindrical tank stores compressed air produced by the air compressor. The stored air is essential for the proper functioning of the truck’s braking system. The reservoir is constructed from durable materials to withstand high-pressure conditions and environmental stressors.
U Bolt and Air Reservoir Bracket Assembly
Itu Kamu baut is used for securing the air reservoir to its mounting bracket. This fastening component ensures that the reservoir remains firmly in place, even under the vibrations and stresses encountered during operation. Itu air reservoir bracket assembly provides a stable support structure for the reservoir. Bersama, these components maintain the reservoir’s alignment and stability, contributing to the overall reliability of the air brake system.
Air Intake Valve Assembly and Air Reservoir Support
Itu air intake valve assembly is crucial for controlling the entry of air into the reservoir. It regulates the flow of air, ensuring that the reservoir is filled to the appropriate pressure levels. Itu air reservoir support provides additional reinforcement to the bracket assembly, enhancing the structural integrity of the air reservoir setup.
Grup Tangki Udara Depan Truk Traktor Seri Dongfeng DFL4251A8-T31R-931-02
Gasket Rings and Elbow Pipe Joint Assembly
Gasket rings are used in various parts of the assembly to prevent air leaks and ensure a tight seal between components. Multiple gasket rings are strategically placed around the connections to maintain pressure within the system. Itu unit sambungan pipa siku facilitates changes in the direction of the air flow, connecting different sections of the pipeline while ensuring a secure and leak-proof connection.
Steel Wire Hook and Plastic Sleeve
Itu steel wire hook is employed to secure various components, termasuk selang dan pipa, to the air reservoir assembly. It provides additional stability and prevents accidental disconnections. Itu plastic sleeve offers protection to the hoses and wiring from abrasion and environmental damage, prolonging their lifespan and maintaining the system’s efficiency.
Catch Strap of Electric Wire Harness and Strap Assembly
Itu catch strap of the electric wire harness organizes and secures the electrical wiring connected to the air reservoir system. This prevents wires from tangling or becoming damaged. Itu strap assembly further secures various components, including the air reservoir, to their respective positions. It ensures that all parts remain correctly aligned and supported throughout the vehicle’s operation.
End Pipe Joint and Reservoir Frame Assembly
Grup Tangki Udara Depan Truk Traktor Seri Dongfeng DFL4251A8-T31R-931-02
Itu end pipe joint connects the air reservoir to other parts of the air brake system, allowing for seamless air transfer. Itu reservoir frame assembly provides a rigid framework that supports the entire air reservoir system. This frame helps maintain the correct positioning of the reservoir and associated components, berkontribusi pada stabilitas keseluruhan sistem.
Unit katup pembuangan air
Itu water drain valve assembly is a critical feature for maintaining the air reservoir’s performance. It allows for the removal of accumulated moisture that can condense within the reservoir. Regular drainage prevents corrosion and ensures that the air system remains free of contaminants that could impair its functionality.
Baut, Kacang, and Screw Plug
Bolts and nuts are used extensively throughout the air reservoir group to secure components in place. These fasteners ensure that all parts of the assembly are tightly connected and remain stable during operation. Itu Steker sekrup is used to seal various openings in the air reservoir assembly, providing an additional layer of protection against leaks.
Air Reservoir Bracket Assembly
Itu air reservoir bracket assembly is a key structural element that holds the air reservoir in place. It consists of various brackets and supports designed to accommodate the reservoir’s size and weight. This assembly ensures that the reservoir remains securely mounted, even under the stresses of regular use.
Kesimpulan
The front air reservoir group of the Dongfeng DFL4251A8-T31R-931-02 series tractor truck is a meticulously designed system comprising multiple components that work together to ensure optimal performance and reliability. From the primary air reservoir assembly to the various supports, tanda kurung, dan perlengkapan, each part plays a crucial role in maintaining the efficiency and safety of the air brake system. Understanding the functions and interconnections of these components is essential for effective maintenance and operation, contributing to the overall reliability and longevity of the vehicle.

Nomor Seri.	Bagian No.	Bagian nama	Jumlah.
1	10490100	Kamu baut,for securing air reservoir	2
	Q340B10	Kacang	8
2	10070000	Air intake valve assembly	1
3	10073800	Cincin paking	4
4	10486800	Majelis Reservoir Udara	2
5	10490800	Kait kawat baja	1
	10092400	Plastic sleeve	1
	10092500	Catch strap of electric wire harness	1
6	10490700	Air reservoir support	2
7	10073700	Cincin paking	2
8	10072300	Sambungan pipa akhir	2
9	10486700	Rakitan bingkai reservoir	1
10	10063500	Unit sambungan pipa siku	1
11	Q1841230	Baut	4
12	Q32012	Kacang	4
13	10073900	Steker sekrup	3
14	10063600	Unit sambungan pipa siku	1
15	10068600	Unit katup pembuangan air	2
16	10481100	Strap assembly	2
	10489800	Air reservoir bracket assembly	2
	Q1841445	Baut	4
	Q32014	Kacang	4
	Q340B10	Kacang	4
