Sinotruk Front Suspension Damper Left Upper Bracket

The Sinotruk Front Suspension Damper Left Upper Bracket is a vital component in the front suspension system of Sinotruk trucks. This assembly includes Hexagonal Flange Face Bolt M10 and Hexagonal Flange Face Nut M10 to ensure secure fastening. The front suspension damper left upper bracket is designed to work in conjunction with the right upper bracket to support the front suspension damper assembly (coil spring, engineering).
Hexagonal Flange Face Bolts with Teeth M14*1.5 and Hexagonal Flange Face Nuts with Teeth M14*1.5 are also used to secure the front suspension damper assembly in place. These components work together with the Pin and Positioning Screw to ensure proper alignment.

Product Parameters of Sinotruk Front Suspension Damper Left Upper Bracket

The right lower bracket of the front suspension damper is also included in this assembly and uses Hexagonal Flange Face Bolts with Teeth M14*1.5 and Hexagonal Flange Face Nuts with Teeth M14*1.5 to fasten securely to the truck frame.
The Right Bracket of the Overturning Transverse Tie Rod is also included in this assembly and is secured with Hexagonal Flange Face Bolts with Teeth M14*1.5 and Hexagonal Flange Face Nut with Teeth M14*1.5.
The Flip Cross-Tie Assembly is secured with Bolt and Cotter Pin to ensure proper alignment and stability. The Grease Nozzle Assembly (Q700B06) is also included to provide lubrication to the components of the assembly.
Finally, the assembly also includes Type 1 Hexagonal Slotted Nut and Limit Block to further ensure secure fastening and proper operation of the front suspension system. The Sinotruk Front Suspension Damper Left Upper Bracket is designed to provide reliable and efficient suspension performance for Sinotruk trucks.

Item	PartNo.	Parts Name	Quantity
1	WG1608434061	Front suspension damper left upper bracket	1
2	ZQ1841050	Hexagonal flange face bolt M10	4
3	ZQ1841030	Hexagonal flange face bolts M10	2
4	ZQ1841020	Hexagonal flange face bolt M10	4
5	ZQ32010	Hexagonal flange face nut M10	4
6	WG1608434062	Front suspension damper right upper bracket	1
7	ZQ1841050	Hexagonal flange face bolts M10	4
8	ZQ1841030	Hexagonal flange face bolts M10	2
9	ZQ1841020	Hexagonal flange face bolt M10	4
10	ZQ32010	Hexagonal flange face nut M10	4
11	WG1608430285	Front suspension damper assembly (coil spring, engineering)	2
12	ZQ1811480TF6	Hexagonal flange face bolts with teeth M14*1.5	2
13	ZQ32514T13F6	Hexagonal flange face nuts with teeth M14*1.5	2
14	WG1608430239	Pin	2
15	Q2861035	Positioning screw	2
16	AZ1608434713	Right lower bracket of front suspension damper	1
17	ZQ1811445TF6	Hexagonal flange face bolts with teeth M14*1.5	3
18	ZQ32514T13F6	Hexagonal flange face nuts with teeth M14*1.5	3
19	Q150B1445	Hexagonal head bolts	1
20	AZ1608434052	Right bracket of overturning transverse tie rod	1
21	ZQ1811445TF6	Hexagonal flange face bolts with teeth M14*1.5	4
22	ZQ32514T13F6	Hexagonal flange face nut with teeth M14*1.5	4
23	Q150B1425	Hexagonal head bolts	3
24	AZ1608434020	Flip cross-tie assembly	1
25	FG1642430071	Bolt	4
26	Q5004045	Cotter pin	4
27	AZ9003963001	Grease nozzle assembly (Q700B06 )	4
28	Q381B16	Type 1 hexagonal slotted nut	4
29	AZ1608434030	Limit block	2
30	AZ1608434031	Limit pad	2
31	Q218B0840	Hexagon socket garden head screws	4
32	Q40012	Small washer	4
33	Q40312	Spring washers	4
34	Q218B0816	Hexagon socket cheese head screws	4
35	ZQ32008	Hexagonal flange face nuts M8	8
36	AZ1608434032	Flip-flop washer	2
37	Q5101455	Cylindrical pin	2
38	Q40114	Flat washers	2
39	Q5004045	cotter pin	2
40	WG1608434035	Flip-flop lifting cylinder	2
41	WG1608434034	Spacer bushing	2
