Sinotruk Lifting Cylinder Lower Bracket Assembly

The Sinotruk Lifting Cylinder Lower Bracket Assembly is a crucial component in the hydraulic lift system of Sinotruk trucks. It is composed of several parts including hexagon head bolts, Type 2 all-metal hexagonal lock nuts, flat washers, self-locking nuts, large washers, hydraulic manual oil pump, small washers, spring washers, lifting cylinder, cab support assembly, and support rod assembly.

Product Parameters of Sinotruk Lifting Cylinder Lower Bracket Assembly

To fasten the bracket assembly securely, hexagon head bolts and Type 1 all-metal hexagonal lock nuts are used. Steel bushing I is included in the assembly to provide additional support. Type I hexagon nuts with fine teeth are used to secure the bushing as well as the bracket assembly. Large washers and spring washers are also included to ensure proper fastening and stability.
The lifting cylinder is an integral part of the assembly and is responsible for the lifting function of the hydraulic system. The cab support assembly is also included to facilitate smooth operation of the lift system. Hexagon head bolts are used to secure the support assembly, while Type 1 hexagon nuts and flat washers are included to prevent unwarranted looseness.
Finally, the assembly is connected to the hydraulic system via a single bend hose (700) and a single bend lift hydraulic oil hose (1100). The Sinotruk Lifting Cylinder Lower Bracket Assembly is designed to provide reliable and efficient lifting performance, while ensuring long-term durability.

Item	PartNo.	Parts Name	Quantity
1	AZ9125820010	Lifting cylinder lower bracket assembly	1
2	Q150B1045	Hexagon head bolts	3
3	Q33210	Type 2 all-metal hexagonal lock nuts	3
4	Q40110	Flat Washer	6
5	Q33216	Self-locking nuts	2
6	Q40216	Large Washer	1
7	Q40116	Flat Washer	2
8	WG9719820001	Hydraulic manual oil pump	1
9	Q150B1020	Hexagon head bolts	2
10	Q40010	Small washers	2
11	Q40310	Spring washers	2
12	WG9125820045	Lifting cylinder	1
13	WG9125820008	Cab support assembly	1
14	Q150B1230	Hexagon head bolts	2
15	Q33412	Type 1 all-metal hexagonal lock nut	2
16	WG9123820009	Support rod assembly	1
17	WG9123820010	Steel bushing I	1
18	Q151B1490	Hexagon head bolts	1
19	Q341B14	Type I hexagon nuts─fine teeth	1
20	Q40214	Large Washer	2
21	Q40314	Spring washers	1
22	Q340B05	Type 1 hexagon nuts	2
23	Q40105	Flat washer	2
24	WG9125820015	Single bend hose(700)	1
25	FG1694821110	Single bend lift hydraulic oil hose (1100)	1
26	WG9125820019	Double bend hose (1300)	1
27	FG1694821320	Double bend lift hydraulic oil hose (1900)	1
28	WG9125820049	Double bend hose (5100)	1
29	WG9123820098	Instruction plate	1
30	Q150B0620	Hexagonal head bolts	1
31	Q40206	Large washer	1
32	Q340B06	I type hexagonal nut	1
33	Q68210	One end fixed single hose clamp piece	2
34	AZ9125820002	Pull strap bracket	1
35	WG9125820040	Plastic bushing I	1
36	WG9125820041	Plastic bushing II	1
37	WG9125820042	Pull strap assembly	1
38	Q40014	Small spacer	3
39	Q40020	Small Washer	1
40	Q5004028	cotter pin	1
41	Q40114	Flat Washer	1
42	Q41814	Corrugated elastic washers	1
43	Q151B14120	Hexagon head bolts (M14X1.5)	1
44	Q341B14	I-type hexagon nuts─fine teeth	1
45	Q40314	Spring washers	1
46	Q40214	Large washers	2
47	Q150B1040	Hexagon head bolts	2
48	Q340B10	Hexagon nuts	3
49	Q40310	Spring washers	3
50	Q40110	Flat washers	3
51	FG1694821310	Single bend lift hydraulic oil hose (500)	1
52	WG9125820020	Double bend hose (900)	1
53	WG1642440070	Tee joint body	2
54	190003 559561	Ferrule	2
55	19000 3559516	Nuts for pipe joints	2
56	Q150B1055	Hexagonal head bolts	1
57	Q68618F4	Single pipe clamp piece	1
58	Q150B1025	Hexagon head bolts	1
59	Q40310	Spring washers	1
60	Q40310	Spring washers	1
61	Q340B10	Hexagonal nut	1
62	AZ9123820013	Hanger hook assembly/81062010018	1
63	FG1694820001	Tee joint body	1
