2024-09-07Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- The Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group – Complete Vehicle is a high-quality assembly designed for the left-hand side pedal system, ensuring durability and functionality within the tractor truck’s cab. This comprehensive kit includes a variety of essential components for a secure and efficient pedal system installation.
Product Parameters of Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- Left Lower Pedal Cover
- The Left Lower Pedal Cover is a crucial component that provides protection and a finished look to the lower pedal area. It guards against wear and tear while enhancing the visual appeal of the pedal assembly.
- LH Lower Pedal Plate
- The LH Lower Pedal Plate forms the core of the pedal system on the left-hand side, offering a sturdy and reliable platform for pedal operation. Its robust design ensures longevity and consistent performance under demanding conditions.
Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- Fastening Components
- This assembly includes various Bolts and Nuts necessary for securing the pedal plate and cover. These components are designed to hold parts firmly in place, with the nuts ensuring a tight and secure fit.
- Spring Nut
- The Spring Nut included in the kit provides flexible and reliable fastening for the pedal components. Its design accommodates varying pressure levels, ensuring that the pedal system remains stable and secure.
- Decoration Cover – Left Lower Pedal
Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- The Decoration Cover – Left Lower Pedal adds an aesthetic touch to the pedal assembly while offering additional protection to the lower pedal area. This cover enhances both functionality and appearance.
- Connecting Beam Welding Assembly (T1)
- The Connecting Beam Welding Assembly (T1) is essential for linking various components of the pedal system. This assembly ensures structural integrity and alignment, contributing to the overall stability of the pedal system.
- Connecting Beam – Frame
- The Connecting Beam – Frame provides crucial support to the pedal assembly, connecting different parts of the frame securely. Its robust construction contributes to the overall strength and reliability of the pedal system.
Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- Reinforced Plate Connecting Beam – Frame
- The Reinforced Plate Connecting Beam – Frame adds extra strength to the connecting beam, ensuring that the frame remains stable and durable even under heavy use.
- Connecting Plate – Frame
- The Connecting Plate – Frame plays a vital role in linking different sections of the frame together. It ensures a secure connection, enhancing the overall stability of the pedal system.
Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- Reinforced Beam
- The Reinforced Beam adds additional support to the pedal assembly, ensuring that the frame remains stable and durable. This beam is designed to handle substantial loads and maintain the integrity of the pedal system.
- Reinforced Plate – Connecting Beam
- The Reinforced Plate – Connecting Beam provides extra support to the connecting beam, ensuring that the pedal system remains secure and resilient.
- Support Beam Assembly – Door Step, One Stair
- The Support Beam Assembly – Door Step, One Stair is designed to provide structural support to the door step area. This assembly ensures that the step remains stable and securely attached.
- Support Beam – Door Step, One Stair
- The Support Beam – Door Step, One Stair offers additional support and stability to the door step, contributing to the overall strength of the assembly.
- Nut and Bolt Assemblies
Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group,Complete Vehicle
- The assembly includes multiple Nuts and Bolts for securing the support beam and other components. These fasteners ensure that all parts of the pedal system and door step assembly are firmly attached and function properly.
- Conclusion
- In summary, the Dongfeng DFL4251A8-T31R-931-02 Series Tractor Truck LH Pedal Plate Group – Complete Vehicle is a comprehensive kit designed to provide a robust and reliable left-hand pedal system. Featuring high-quality components such as the LH lower pedal plate, various bolts, nuts, and reinforced structural elements, this assembly ensures durability, stability, and optimal performance for the tractor truck.
| Serial No. | Part No. | Part Name | Qty. |
| 1 | 10516600 | Left lower pedal cover | 1 |
| 2 | Q1840620-F7 | Bolt | 2 |
| 3 | Q32010 | Nut | 2 |
| 4 | 10425600 | LH lower pedal plate | 1 |
| 5 | Q1840625-F7 | Bolt | 2 |
| 6 | 10144800 | Spring nut | 2 |
| 7 | 10516400 | Decoration cover- left lower pedal | 1 |
| 8 | Q150B0825-F7 | Bolt | 4 |
| 9 | 10425900 | Connecting beam welding assembly(T1) | 1 |
| 10683000 | Connecting beam- frame | 1 | |
| 10683100 | Reinforced plate Connecting beam- frame | 2 | |
| 10683300 | Connecting plate- frame | 1 | |
| 10683400 | Reinforced beam | 1 | |
| 10683200 | Reinforced plate- Connecting beam | 2 | |
| 10 | Q1841025-F7 | Bolt | 9 |
| 11 | 10425800 | Support beam assembly- door step,one stair | 1 |
| 10682900 | Support beam- door step,onestair | 1 | |
| 12 | Q32010-F7 | Nut | 4 |
| 13 | 10516800 | Support- door step,one stair | 2 |
| 14 | Q1841235-F7 | Bolt | 4 |
| 15 | Q32012-F7 | Nut | 4 |
| Q32008-F7 | Nut | 4 |
