LOWER SLEEPER

LOWER SLEEPER

序 号

NO

件 号

Part.No

名 称

Designation

Name

数 量

Quantity

适用车型

Suited type

备 注

Remark



DZ1643370030

卧铺总成

bunk assembly

1





1

81.62159.6268

卧铺总成

bunk assembly



1



2

81.62160.5143

卧铺垫总成

covering assembly

1



3

81.62159.5229

板总成

plate assembly

2



4

06.04209.0030

平头螺钉

pan-head screw

4

M8×16-4.8-H-A3R

5

06.15019.0084

washer



4

A8.4×16×1.6-200HV-











MAN183-B4

6

81.90713.0004

washer

2

12.5×25×2.5

7

06.15019.0084

washer

2

A8.4×16×1.6-200HV-











MAN183-B4

8

06.11240.0604

六角锁紧螺母

hex lock nut



2

BM8-8-MAN184-B4

9

81.62150.6017

保护架总成

securing clip assembly

1



10

81.62150.6016

锁止架总成

retainer, left assembly

1



11

81.62150.0023

安全装置轴承支架

bracket



1



12

06.46080.0340

压缩弹簧

pressure spring

2

2.5×12.5×47.5

13

06.04299.0009

沉头螺钉

counteraunk screw

1

M8×90×34-4

14

06.04299.0010

沉头螺钉

counteraunk screw

1

M8×100×34-4

15

06.15019.0084

washer



2

A8.4×16×1.6-200HV-











MAN183-B4

16

06.11240.0604

六角锁紧螺母

hex lock nut

2

BM8-8-MAN183-B4

17

06.04209.0030

盘头螺钉

pan-head screw

6

M8×16-4.8-H-A3R

18

06.15019.0084

washer



6

A8.4×16×1.6-200HV-











MAN183-B4

19

81.96020.0129

橡胶垫

rubber pad

2

26.5×29.5×19-8
