LEFT DOOR STEP
2022-08-09
COVERING FOR REAR PANEL
2022-08-09LEFT DOOR STEP
2022-08-09COVERING FOR REAR PANEL
2022-08-09RIGHT DOOR STEP
序 号 NO | 件 号 Part.No | 名 称 Designation | Name | 数 量 Quantity | 适用车型 Suited type | 备 注 Remark |
1 | 81.61510.0226 | 右门台阶 | Step right | 1 |
| 高位踏板 |
| 81.61510.0230 | 右门台阶 | Step right | 1 | 低位踏板 | |
2 | 81.61510.5162 | 右装饰件总成 | Trim assembly right
| 1 | 高位踏板 | |
| 81.61510.5164 | 右装饰件总成 | Trim assembly right
| 1 | 低位踏板 | |
3 | 06.15190.0309 | 垫 片 | Washer | 3 | 8.4×24×2-140HV-MAN183-B4 | |
4 | 06.11069.0114 | 螺 母 | Hexagon nut | 3 | M8-8-MAN183-B4 | |
5 | 81.61510.0268 | 右上台阶 | Step right upper | 1 |
| |
6 | 81.61510.0262 | 右中间台阶 | Step center
| 1 |
| |
7 | 81.61510.5196 81.61510.5181 | 右下台阶 下台阶 | Step assembly right lower black Step | 1 2 | 高位踏板 HIGH POSITION | |
8 | 06.01320.1314 | 螺 栓 | Hex bolt | 14 | STEP | |
9 | 06.15019.0081 | 垫 片 | Washer
| 14 | 低位踏板 LOWER STEP | |
10 | 06.15190.0309 | 垫 片 | Washer | 14 | M8×22-8.8-MAN183-B4 | |
11 | 06.11069.0114 | 螺 母 | Hexagon nut | 14 | A8.4×16×1.6-200HV- | |
|
|
|
|
| MAN183-B4 | |
|
|
|
|
| 8.4×24×2-140HV-MAN183-B4 | |
|
|
|
|
| M8-8-MAN183-B4 |
