Sinotruk Bumper Assembly

The Sinotruk Bumper Assembly is a comprehensive package that consists of various components essential for the installation of the bumper assembly. It includes hexagon head bolts, spring washers, and large washers that are used to secure the bumper assembly in place. The package also includes the bumper lower trim plate assembly, which comprises the lower bumper trim plate and lower bumper grille.
To ensure a secure fit, cross recessed pan head self-tapping screws and flat washers are included. The front footrest is equipped with anti-slip rubber to provide added safety. The package also contains a letter buckle, cross recessed pan head screws, and a combination of flat washers for assembly purposes.

Product Parameters of Sinotruk Bumper Assembly

The upper bumper grille is included as well, along with I-type hexagon nuts, spring washers, and large washers for secure fastening. The bumper assembly assembly also features the bumper left vent, bumper right vent, bumper left cover plate, and bumper right cover plate for a complete look. Additionally, a traction pin over hole plug cover is included to provide protection and aesthetics.
The Sinotruk Bumper Assembly ensures a hassle-free installation of the bumper, providing both functionality and visual appeal to your vehicle.

Ite m	PartNo	Parts Name	Quantity
1	WG1632246002	Bumper assembly assembly	1
2	Q150B1230	Hexagon head bolts	4
3	Q40312	Spring washers	4
4	Q40212	Large Washer	4
5	WG1632246002	Bumper Assembly	1
6	AZ1632246006	Bumper lower trim plate assembly	1
7	WG1632246007	Lower Bumper Trim Plate	1
8	WG163224600 8	Lower Bumper Grille	1
9	Q2714216	Cross recessed pan head self-tapping screws	10
10	Q40105	Flat washers	10
11	WG163224600 9	Front footrest anti-slip rubber	1
12	AZ1632246016	Letter buckle	5
13	Q2300620	Cross recessed pan head screws and flat washers combination	4
14	Q2140620	Cross recessed pan head screws	8
15	Q40105	Flat washers	8
16	WG163224601 0	Upper bumper grille	1
17	Q340B06	I-type hexagon nuts	10
18	Q40306	Spring washers	10
19	Q40206	Large Washer	10
20	WG163224601 1	Bumper left vent	1
21	WG163224601 2	Bumper right vent	1
22	WG163224601 3	Bumper left cover plate	1
23	WG163224601 4	Bumper Right Cover	1
24	WG163224601 5	Traction pin over hole plug cover	1
25	Q2714813	Cross recessed pan head tapping screws	6
26	Q40105	Flat Washer	6
27	WG163224601 7	Left pedal frame	1
28	WG163224601 8	Right pedal frame	1
29	WG163223600 5	Left pedal grille	1
30	WG163223600 6	Right pedal grille	1
31	Q340B06	Type I hexagonal nuts	12
32	Q40206	Large Washer	12
33	Q40306	Spring Washer	12
34	WG912593020 1	Pedal bracket assembly(336PS)	1
35	Q150B1435	Hexagon head bolts	6
36	Q340B14	Type 1 hexagon nuts	6
37	199012930020	Pin Assembly	1
38	FG9831930300	Bumper transition bracket (Golden Prince)	2
39	MQ6W90410- 0014	Twelve-angle bolt	4
40	MQ6W41610- 0249	Washer	4
41	SZQ341C12	Nut plate	4
