Sinotruk Howo Steering Control Mechanism

  • The Sinotruk Howo Steering Control Mechanism consists of various components that work together to ensure smooth steering operation. The key components and their functionalities are as follows:
  • Steering shaft with pipe assembly: This component connects the steering wheel to the steering mechanism and allows for rotational movement.
  • Steering wheel: The steering wheel is the primary control interface for the driver to steer the vehicle in the desired direction.
  • Contact ring: The contact ring enables the electrical connection for various controls mounted on the steering wheel, such as audio controls or cruise control.
  • Hexagon thin nut: A type of nut used for securing and tightening the steering components.
  • Wave elastic washer: This washer acts as a cushion and absorbs any vibrations or shocks that may occur during steering.
  • Shaft elastic ring: A ring designed to provide flexibility to the steering shaft while maintaining its stability.
  • Deep groove ball bearings 61905GB/T276-94: These bearings facilitate smooth rotation of the steering mechanism.
  • Steering shaft: The steering shaft transfers the rotational motion from the steering wheel to the steering mechanism.
  • Key start switch: This switch is used to start the vehicle’s engine by turning the ignition key.
  • Hex head bolt: Another type of bolt used for fastening and securing steering components.
  • Type 1 hex nut: A specific type of nut used in the assembly of the steering mechanism.
  • Roller: The roller is responsible for reducing friction and ensuring smooth movement in the steering system.
  • Securing clip: This clip securely fastens the steering components together to prevent any disassembly during operation.
  • Steering sleeve: The steering sleeve connects the steering shaft to the steering column, allowing for rotational movement.
  • Compressed spring: This spring provides tension and flexibility to the steering mechanism, ensuring responsive steering.
  • Shim: A thin piece of material used for alignment and adjustment purposes in the steering control mechanism.
  • Bearing: Bearings support the moving parts of the steering mechanism, reducing friction and providing smooth operation.
  • Hex head bolt: Another type of bolt used for fastening and securing the steering components.
  •

Product Parameters of Sinotruk Steering Control Mechanism

Steering Control Mechanism
  • Steering column cover (rear): This cover protects the rear part of the steering column, providing a clean and finished look.
  • Cross recessed pan head tapping screws: These screws are used to secure the steering column cover.
  • Travel limit screw: This screw limits the maximum movement of the steering mechanism, preventing oversteering.
  • Spring washer: A washer with spring-like properties that provides tension and prevents loosening of bolts.
  • Flexible plate: This plate allows for slight adjustments and flexibility in the steering mechanism.
  • Adjust the fastening bolt: This bolt is used to adjust the tightness of the steering components for optimal performance.
  • Compressed spring: Another compressed spring that adds tension and flexibility to the steering system.
  • Wire harness fixing bracket: A bracket used to secure the wire harness connected to various control components.
  • Hex head bolt: Another type of bolt used for fastening and securing the steering components.
  • Spring washer: A washer with spring-like properties that provides tension and prevents loosening of bolts.
  • Flat Washers: These washers distribute the load evenly and provide a smooth surface for bolt tightening.
  • Steering column cover (front): Similar to the rear cover, this cover protects and gives a finished appearance to the front part of the steering column.
  • Cross recessed pan head tapping screws: These screws are used to secure the front steering column cover.
  • Adjust the handwheel: The handwheel can be adjusted to the desired position for comfortable steering.
  • Washer: A flat circular piece used to distribute the load and provide a smooth surface for bolt tightening.
  • Steering column guide sleeve: This sleeve guides the steering column, ensuring smooth and stable movement.
  • Steering column mounting bracket: A bracket used to securely mount the steering column.
  • Hex head bolt: Another type of bolt used for fastening and securing the steering column mounting bracket.
  • Type 1 hex nut: A specific type of nut used in the assembly of the steering mechanism.
  • Spring washer: A washer with spring-like properties that provides tension and prevents loosening of bolts.
  • Flat Washers: These washers distribute the load evenly and provide a smooth surface for bolt tightening.
  • Deep groove ball bearings: These bearings provide smooth rotation and reduce friction between the steering components.
Serial Name Part Number
0 Steering shaft with pipe assembly AZ9719470050
1 Steering wheel AZ9719470100
2 Contact ring AZ9130583024
3 Hexagon thin nut Q351B22T15
4 Wave elastic washer Q41822
6 Shaft elastic ring Q43125
7 Deep groove ball bearings 61905GB/T276-94 AZ9003320012
8 Steering shaft AZ9719470053
9 Key start switch WG9130583019
10 Hex head bolt Q150B0530
11 Type 1 hex nut Q340B05
12 Roller 81.95801.0071
13 Securing clip 81.46433.0005
14 Steering sleeve AZ9719470051
15 compressed spring AZ9123470129
16 Shim AZ9123470130
17 Bearing AZ9100470424
18 Hex head bolt Q150B0865
19 Steering column cover (rear) AZ9719470041
20 Cross recessed pan head tapping screws Q2720412
21 Travel limit screw AZ9719470057
22 Spring washer Q40316
23 Flexible plate AZ9719470058
24 Adjust the fastening bolt AZ9719470055
25 compressed spring AZ9123470153
26 Wire harness fixing bracket AZ9719470052
27 Hex head bolt Q150B0408
28 Spring washer Q40304
29 Flat Washers Q40104
30 Steering column cover (front) AZ9719470042
31 Cross recessed pan head tapping screws Q2714250
32 Adjust the handwheel AZ9123470150
33 washer AZ9123470155
34 Steering column guide sleeve AZ9719470054
35 Steering column mounting bracket AZ9719470056
36 Hex head bolt Q150B0830
37 Type 1 hex nut Q340B08
38 Spring washer Q40308
39 Flat Washers Q40108
40 Deep groove ball bearings AZ9003320013
41 Shaft elastic ring Q43130
42 ring 81.91710.0459
43 Hole elastic ring Q43042
44 Universal joint AZ9719470043
45 Steering extend shaft AZ9719470044
46 Face projection bolt Q199B0616
47 Type 1 hex nut Q340B06
48 Spring washer Q40306
49 Flat Washers Q40106
50 Steering shaft sheath AZ9719470045
51 Pressure plate AZ9719470046
52 bushing AZ9100470410
1a Return ring WG9130583018
