Sinotruk Howo INTAKE EXHAUST (TWO VALVES)

  1. Cylinder body: The cylinder body forms the main structure of the engine, housing the combustion chamber where the intake and exhaust processes take place.
  2. Crankshaft case: The crankshaft case encloses the crankshaft and provides support for various engine components, including the intake and exhaust systems.
  3. Intake manifold gasket: The intake manifold gasket forms a seal between the intake manifold and the cylinder head, preventing air or fuel leaks and ensuring proper intake efficiency.
  4. Intake pipe: The intake pipe connects the intake manifold to the air filter or turbocharger, allowing the intake of fresh air into the combustion chamber.
  5. Stud: Studs are used to secure and fasten different components of the intake and exhaust systems, ensuring a tight and stable assembly.
  6. Hex nuts: Hex nuts are used in conjunction with studs to secure and tighten connections within the intake and exhaust systems.
  7. Wave spring washers: Wave spring washers provide tension and help absorb shock or vibration in the intake and exhaust systems, ensuring a secure attachment of components.
  8. Inlet connection: The inlet connection connects the intake manifold to the air filter housing, allowing the intake of filtered air.
  9. First, two cylinder exhaust manifold: The two-cylinder exhaust manifold collects and channels the exhaust gases from the first two cylinders towards the exhaust system.
  10. Third, four-cylinder exhaust manifold: The four-cylinder exhaust manifold collects and channels the exhaust gases from the third to the sixth cylinder towards the exhaust system.
  11. Fifth, six-cylinder exhaust manifold: The six-cylinder exhaust manifold collects and channels the exhaust gases from the fifth to the eighth cylinder towards the exhaust system.
  12. Exhaust pipe sealing ring: The exhaust pipe sealing ring forms a tight seal between exhaust pipes, preventing exhaust gas leaks and maintaining proper flow.
  13. Exhaust pipe gaskets: The exhaust pipe gaskets create a seal between different sections of the exhaust system, preventing exhaust gas leaks.
  14. Exhaust pipe fastening bolts: Exhaust pipe fastening bolts secure the exhaust pipes, ensuring a tight and secure connection.
  15. Support: Supports provide stability and hold components in place within the intake and exhaust systems.
  16. Hex head bolts: Hex head bolts are used to fasten and secure different components of the INTAKE EXHAUST (TWO VALVES) system, ensuring a reliable assembly.
  17. Turbocharger: The turbocharger increases the engine’s power output by compressing the intake air, resulting in improved combustion efficiency.
  18. Turbocharger gasket: The turbocharger gasket forms a reliable seal between the turbocharger and the engine, preventing air or exhaust leaks.
  19. Turbocharger inlet pipe: The turbocharger inlet pipe connects the turbocharger to the intake manifold, allowing compressed air to enter the combustion chamber.
  20. Inlet pipe flange: The inlet pipe flange connects the inlet pipe to the turbocharger, ensuring a secure and tight connection.
INTAKE EXHAUST (TWO VALVES)
Download Catalog
WhatsApp
Get Quotation

Product Parameters of Sinotruk Howo INTAKE EXHAUST (TWO VALVES)

  • 21. Inlet pipe gasket: The inlet pipe gasket forms a seal between the inlet pipe and the turbocharger, preventing air leaks and maintaining proper pressure.
  • 22. Hexagon socket head screws: Hexagon socket head screws are used to secure and tighten connections within the turbocharger inlet pipe assembly.
  • 23. Self-locking washer: Self-locking washers provide additional security and prevent loosening of connections within the turbocharger inlet pipe assembly.
  • 24. Self-locking nuts: Self-locking nuts securely hold and fasten different components of the turbocharger inlet pipe assembly, ensuring a reliable connection.
  • 25. Turbocharger oil return pipe assembly: The turbocharger oil return pipe assembly allows for the return of oil from the turbocharger to the engine’s oil system.
  • 26. Return pipe flange gasket: The return pipe flange gasket forms a seal between the return pipe and the engine, preventing oil leaks.
  • 27. Return pipe bolt: Return pipe bolts secure the return pipe, ensuring a tight and secure connection.
  • 28. Seals: Seals are utilized to prevent oil leaks and maintain proper lubrication within the turbocharger oil return pipe assembly.
  • 29. Clips: Clips secure and hold components in place within the INTAKE EXHAUST (TWO VALVES) system, ensuring a stable and reliable assembly.
  • 30. Rubber hose: Rubber hoses are used in the INTAKE EXHAUST (TWO VALVES) system to facilitate the flow of air or fluids between different components.
  • 31. Hose clamps: Hose clamps secure the rubber hoses to their respective connections, ensuring a tight and leak-free seal.
  • 32. Front shrouds: Front shrouds provide protection and direct airflow within the INTAKE EXHAUST (TWO VALVES) system to optimize cooling.
  • 33. Shrouds: Shrouds help control airflow and direct it towards specific components within the INTAKE EXHAUST (TWO VALVES) system.
  • 34. Small Washers: Small washers provide additional support and stability within the INTAKE EXHAUST (TWO VALVES) system.
  • 35. Heat shield bolt: Heat shield bolts secure the heat shield, protecting nearby components from excessive heat.
  • 36. Hexagon head screw plugs: Hexagon head screw plugs are used to seal unused holes or openings in the INTAKE EXHAUST (TWO VALVES) system.
  • 37. Turbocharger coupling elbow: The turbocharger coupling elbow connects the turbocharger to the intake manifold, facilitating the airflow.
  • 38. Turbocharger intake pipe: The turbocharger intake pipe connects the turbocharger to the intake manifold, allowing the intake of compressed air.
INTAKE & EXHAUST (TWO VALVES), D10 ENGINE EURO-III
SerialNameNumber
1Cylinder bodyaz1095010010
2Crankshaft case161500010369
3Intake manifold gasketvg1500110024
4Intake pipevg1540110036
5Studq1201030f3
vg1560110187
6Hex nutsq340b10
7Wave spring washersq41810
8Inlet connectionvg1095110100
9First, two cylinder exhaust manifoldvg1540110145
10Third, four-cylinder exhaust manifoldvg1540110146
11Fifth, six-cylinder exhaust manifoldvg1540110147
12Exhaust pipe sealing ringvg1540110005
13Exhaust pipe gasketsvg1560110111
14Exhaust pipe fastening boltsvg1246110052
15Supportvg1099110006
16Supportvg1095110102
17Hex head boltsq150b0820
18Hex head boltsvg1560110241
19Turbochargervg1034110051
20Turbocharger Gasketvg1560110210
21Turbocharger inlet pipevg1095110015
22Inlet pipe flangevg1099110008
23Inlet pipe gasketvg609e110050
24Hexagon socket head screws90003862428
25Self-locking washervg188250083
Self-locking nuts190003888470
26Turbocharger oil return pipe assemblyvg1095110025
27Return pipe flange gasketvg2600110048
28Return pipe boltvg1460070014
29Sealsvg190320035
30Clipsvg1560110226
31Rubber hosevg9112530148
32Hose clamps190003989315
33Front shroudsvg1099110004
34Shroudsvg1099110005
35Small Washers190014320002
36Heat shield boltvg2600110963
37Hexagon head screw plugs190003962051
38Turbocharger coupling elbowvg1099110002
39Turbocharger intake pipevg1099110003
