2023-10-18Sinotruk Howo Second Shaft Gearing Bushing & Gear
- The Sinotruk Howo Second Shaft Gearing Bushing & Gear is a vital component in the transmission system of the Sinotruk Howo trucks. It consists of several key parts, including:
- Second shaft sleeve: This sleeve provides support for the second shaft and helps to reduce friction during gear shifting.
- Adjusting pad: The adjusting pad is used to align the gears properly and ensure smooth operation of the transmission.
- Second gears splined washer: This washer is responsible for connecting the second gears to the splined portion of the second shaft.
- Second shaft gear splined washer: Similar to the previous washer, this component connects the second shaft gear to the splined portion of the second shaft.
- Second shaft third gear: The third gear on the second shaft is responsible for transmitting power at a particular speed ratio.
Product Parameters of Sinotruk Howo Second Shaft Gearing Bushing & Gear
- Second shaft overdrive gear: This gear allows for higher speed ratios and is engaged during overdrive operation.
- Second shaft fourth gear: The fourth gear on the second shaft provides another speed ratio for the transmission.
- Snap ring: The snap ring ensures that the gears and washers are securely held in place on the second shaft.
- First shaft second gear: This gear on the first shaft engages with the second gear on the second shaft to transmit power.
- Second shaft second gear: Similar to the previous gear, this gear on the second shaft engages with the first shaft second gear.
- Second shaft two gear: The two gear on the second shaft provides a specific speed ratio for the transmission.
- Second shaft first gear: The first gear on the second shaft is responsible for providing the lowest speed ratio in the transmission.
- Second shaft low gear: This gear provides the lowest speed ratio for heavy-duty operations or climbing steep gradients.
- Second shaft reverse gear: The reverse gear on the second shaft allows for backward movement of the vehicle.
- Elastic cylindrical pin: The elastic cylindrical pin is used to secure various components in place on the second shaft.
- Second shaft hex key: The hex key is used to tighten or loosen the fasteners on the second shaft.
- Second shaft: The second shaft itself is an essential part of the transmission system, responsible for transferring power from the engine to the wheels.
- The Sinotruk Howo Second Shaft Gearing Bushing & Gear assembly plays a crucial role in ensuring smooth and efficient gear shifting in the Sinotruk Howo trucks. With proper maintenance and regular inspection, these components can provide reliable performance and contribute to the overall durability of the transmission.
| Second shaft gearing bushing & gear | |||||||||||||||||||
| sequence | name | part number | |||||||||||||||||
| 1 | Second shaft sleeve | 16118 | |||||||||||||||||
| 1 | Second shaft sleeve | jsl30t-1701108 | |||||||||||||||||
| 2 | Adjusting pad | 1870l | |||||||||||||||||
| 3 | Second gears splined washer | jsl00-1701113 | |||||||||||||||||
| 3 | Second shaft gear splined washer | 14749 | |||||||||||||||||
| 4 | Second shaft third gear | 19242 | |||||||||||||||||
| 4 | Second shaft overdrive gear | tll6e-1701132 | |||||||||||||||||
| 4 | Second shaft fourth gear | jsl30ta-1701131 | |||||||||||||||||
| 4 | Second shaft fourth gear | jsl00a-1701131 | |||||||||||||||||
| 4 | Second shaft third gear | jsl00t-1701131 | |||||||||||||||||
| 4 | Second shaft third gear | jsl00―1701131 | |||||||||||||||||
| 4 | Second shaft fourth gear | _1s10gra-1701131 | |||||||||||||||||
| 4 | Second shaft third gear | jsl80t-1701131 | |||||||||||||||||
| 4 | Second shaft overdrive gear | 19638 | |||||||||||||||||
| 4 | Second shaft third gear | 16748 | |||||||||||||||||
| 4 | Second shaft override gear | jsl50-1701113 | |||||||||||||||||
| 5 | Snap ring | 14750 | |||||||||||||||||
| 6 | First shaft second gear | jsl50-1701112 | |||||||||||||||||
| 6 | Second shaft second gear | jsl80t-1701130 | |||||||||||||||||
| 6 | Second shaft two gear | 19614 | |||||||||||||||||
| 6 | Second shaft two gear | 19622 | |||||||||||||||||
| 6 | Second shaft two gear | jsl30t-1701130 | |||||||||||||||||
| 6 | Second shaft two gear | 16750 | |||||||||||||||||
| 6 | Second shaft second gear | jsl00t-1701130 | |||||||||||||||||
| 7 | Second shaft first gear | jsl50-1701111 | |||||||||||||||||
| 7 | Second shaft first gear | jsl30t-1701112 | |||||||||||||||||
| 7 | Second shaft first gear | jsl00t-1701112 | |||||||||||||||||
| 7 | Second shaft first gear | 19246 | |||||||||||||||||
| 7 | Second shaft first gear | jsl00-1701112 | |||||||||||||||||
| 7 | Second shaft first gear | 19628 | |||||||||||||||||
| 7 | Second shaft first gear | jsl80t-1701112 | |||||||||||||||||
| 7 | Second shaft first gear | 16752 | |||||||||||||||||
| 8 | Second shaft low gear | 16754 | |||||||||||||||||
| 9 | Second shaft reverse gear | jsl00-1701111 | |||||||||||||||||
| 9 | Second shaft reverse gear | jsl80t-1701111 | |||||||||||||||||
| 9 | Second shaft reverse gear | 16756 | |||||||||||||||||
| 10 | Elastic cylindrical pin | 62504 | |||||||||||||||||
| 11 | Second shaft hex key | 17109 | |||||||||||||||||
| 12 | Second shaft | jsl30t-1701105 | |||||||||||||||||
| 12 | Second shaft | jsl80t-1701105 | |||||||||||||||||
| 12 | Second shaft | 18729 | |||||||||||||||||
| 12 | Second shaft | jsl80-1701105 | |||||||||||||||||
