Sinotruk Howo Turbo Cylinder

The Sinotruk Howo Turbo Cylinder is a crucial component of the vehicle’s turbocharging system. It is responsible for increasing the engine’s performance by improving air intake and enhancing combustion efficiency.
The Turbo Cylinder consists of various essential parts, including hexagon head bolts and a spring washer. These components ensure a secure connection and help in keeping the turbo cylinder in place.
Another important component is the cylinder head gasket, which provides a tight seal between the cylinder head and the engine. This prevents any leakage of gas or coolant.

Product Parameters of Sinotruk Howo Turbo Cylinder

The Turbo Cylinder also features an O-ring, which helps in maintaining a tight seal and preventing any air or fluid leaks. This is vital for the proper functioning of the turbocharging system.
The center position cylinder head is responsible for maintaining the correct alignment and stability of the turbo cylinder assembly. It ensures that all the components are properly positioned and secured.
A normally open vent plug is included in the Turbo Cylinder design to release excess pressure. This helps in preventing any potential damage to the system and ensures optimal performance.
The Turbo Cylinder also incorporates an intermediate position cylinder, which houses a shaft with an elastic ring. This shaft plays a crucial role in driving the turbocharger and controlling its speed.
Additionally, there are O-rings included in the Turbo Cylinder assembly to provide additional sealing and prevent any leaks.
The piston connection shaft connects the piston to the turbocharger, enabling the transfer of power from the engine to the turbocharging system.
Furthermore, a locating ring is incorporated into the Turbo Cylinder to ensure proper alignment and positioning, guaranteeing optimal performance.
In conclusion, the Sinotruk Howo Turbo Cylinder is an essential component of the turbocharging system, ensuring increased engine performance. Its various components, such as the hexagon head bolts, gasket, O-rings, and vent plug, work together to provide a secure and efficient turbocharging process. The incorporation of the shaft, piston connection, and locating ring further enhances the performance and stability of the Turbo Cylinder.

Serial	P/N	Name	Qty in a Gearbox
1	Q14210115	Hexagon head bolts and spring washer	4
2	14349	Cylinder head gasket	1
3	14344	O-ring	1
4	QH70-4211407-1	Center position cylinder head	1
5	Q901	Normally open vent plug	1
6	QH70-4211402-2	Intermediate position cylinder	1
7	Q43117	Shaft with elastic ring	1
8	14765	O-ring	1
9	QH70-4211406-1	Piston connection shaft	1
10	QH70-4211404	Locating ring	1
11	14344	O-ring	1
